CNC Busbar Dabtsi Yog Khoov Tshuab

Qhov ntev: 1890*1350*1400mm
Muaj nuj nqi: Txiav, Dabtsi Yog Khoov, Xuas Nrig Ntaus
Qhov siab tshaj plaws: 15mm
Qhov siab tshaj plaws: 160mm

Xa kev nug

Hauj lwm lawm

Khoom Paub meej

DS-303SK-B Copper busbar tej tshuab

Lub luag haujlwm tseem ceeb yog ua cov txheej txheem ntau yam tshwj xeeb ntawm tooj liab thiab txhuas tsheb npav. Xuas nrig ntaus, txiav, khoov, kos duab thiab lwm yam haujlwm ntawm lub npav npav tuaj yeem ua tiav ntawm chav ua haujlwm sib xws.

Lub rooj loj-slab, qhov zoo li yog txiav laser, saum npoo yog ua tiav los ntawm lub ntsej muag loj loj, thiab saum npoo tau kho nrog nyuaj chromium plating, thiab saum npoo yog tiv thaiv xeb, xeb, thiab txhuam tsis kam.

Cov khoom siv ntawm lub tshuab tig yog lub ntsej muag cam khwb cia hlau, tsis hloov pauv, ua tiav los ntawm lub tshuab ua haujlwm kom raug kom ntseeg tau qhov tseeb, thiab cov nplaim tau kho nrog cov tshuaj nickel plating ci, uas zoo nkauj thiab tsis ploj.

Khoom Parameter

Qauv Tsis	DS-303SK-B
Xim	Xiav
Punch	Max. Punch Force	300kn ua
	Punch Diameter	.34.3 - ∅30 hli
	Max. Thickness	15 hli
	Max. Dav	160 hli
Txiab Txiav	Max. Txiav Force	500kn ua
	Max. Txiav Thickness	15 hli
	Max. Txiav Dav	160 hli
Kab rov tav khoov	Max. Punch Force	300kn ua
	Max. Thickness	15 hli
	Max. Dav	160 hli
Ntsug khoov	Max. Dav	10 x 100
Ntsug khoov	Max. Lub (Degree)	90°
Qhov ntev	MM	189013501400 hli
Lub zog Moteur	KW	*34**
Qhov hnyav	KG	1300
CNC Precision	Khoov Precision	±1°
CNC Precision	Rov Qab Khoov Qhov Ncauj	±0.2°

Avantage

1. Cov ko taw hloov kho tau: txhawm rau ua kom ruaj khov ntawm cov cuab yeej siv.

2. Lub cev muaj zog ywj pheej: 3 chaw nres tsheb ua haujlwm tib lub sijhawm, zam kev tsav lub cev puas tsuaj los ntawm kev ua haujlwm ntau dhau.

3. Kev tiv thaiv hluav taws xob: kev tshuaj xyuas lub sijhawm tiag tiag ntawm lub tshuab ua haujlwm, kev siv lub zog tsis siv neeg tiv thaiv lub cav thiab lwm yam khoom tseem ceeb.

4. Kev ua tau ntev: Cov khoom siv hluav taws xob ntawm Siemens, Schneider thiab lwm yam khoom lag luam loj yog cov khoom ruaj khov thiab zam kev laus ntawm Circuit thiab ua rau luv Circuit Court.

5: Kev tiv thaiv kev nyab xeeb: tiv thaiv lub tshuab los ntawm kev ua rau cov ntiv tes lossis lwm yam khoom thaum lub tshuab ua haujlwm.

6: Nres sai: thaum muaj xwm ceev, nres tam sim.

Tuam txhab Profile

Jinan Deshang CNC Equipment Co., Ltd. tau tsim nyob rau lub Xya Hli 29, 2005 nrog cov peev txheej ntawm 10 lab. Lub tuam tsev muag khoom lag luam txawv teb chaws tau tsim nyob rau xyoo 2020. Lub Hoobkas muaj CNC chaw ua haujlwm, tshuab dhos CNC, tshuab tho txawv, thiab tshuab milling.

Cov khoom tseem ceeb: CNC npav tshuab, portable hydraulic tooj liab ua tshuab, tshuab winding, qib tshuab, vuam tshuab, thiab lwm yam.

Peb tau dhau ISO9001 thiab CE daim ntawv pov thawj. Peb lub tuam txhab' cov khoom tau raug xa tawm mus rau sab Asia, Europe, Russia, South America, North America, Africa thiab ntau lub tebchaws.
